- Size: 1950*3100*1650
- Place of Origin: JINAN
- Brand Name: xunke
- Model Number: XK-1325
- Weight: 800.000 kg
machine type | XK-1325- Install shaft pressing device | Optional configuration |
Working stroke | 1300*2500*200 | customizable |
Machine construction | Steel bed | Square tube structure bed / Mesa of adsorption |
machine size | 1950*3100*1650 |
|
Spindle power | 4.5KWAir cooling spindle | Specify the power / Air cooling / Multi head |
Maximum working speed | 20m/min |
|
Working voltage | AC380V,50HZ | AC220V,50HZ |
operating system | D macro system | DSP handle or specify the system |
Way of working | Hybrid servo motor | Stepper motor/servo motor |
Carving instruction | G 代码, HPGL,U00 , mmg , plt |
|
Transmission mode | XYRack drive shaft , Z-axis ball screw drive |
|
Material fixed | Clamp platen , Installation of pneumatic device finale |
|
orbit | Three axis import square rail |
|
Available tools | φ3.175-φ12.7 |
|
|
|
|
1, adopts imported linear square guide rail, double row and four row ball slider, loading capacity is big, smooth operation, high precision, long service life.
2, imported high precision ball screw, the knife precision.
3, using air cooling spindle, big power, the effect is good. Ac servo motor running speed, big power.
4, good software compatibility, is compatible with type3 / Artcam/Castmate/wen tai and other CAD/CAM design software.
5, add the closing device, can be fixed materials for a wide variety of sizes. Two roller spacing size can adjust at will, can use large area of cutting hollow out, also can undertake small cutting work.
6, adopts high speed drive and stepper motor drives, Y axis adopt double motor drive, to speed up to 35 m/min or more empty lines speed, with strong cutting spindle can make engraving speed more increase.
